High Precision Battery Pack Assembly Equipment 18650 Pneumatic Spot
Welder
Equipment introduction
● Adopting single-chip computer control, it can realize single
pulse, multi-pulse and double-pulse welding.
● The lithium battery welder adopts proprietary output energy
optimization algorithm, with reasonable output voltage and output
current conversion, strong welding capacity, firm welding joints,
no miswelding, low ignition and excellent surface quality.
● Independent welding pin, spring cushion design, precise
adjustment of welding pressure.
● The welding head platform can be adjusted up and down, and can
weld various sizes of batteries.
● Imported alumina copper electrode, pure purple copper welding
cable, pure copper electrode chuck and other high quality
accessories, the machine is durable.
● Intelligent chip precision control, imported control chip,
microsecond corresponding chip integration process, small size, can
work for a long time, and stable operation.
● All parameters are set digitally, and the parameter adjustment is
stable, intuitive and accurate.
● Welding adopts vertical spot welding, with adjustable pressure
depth.
● Pneumatic precision welding head developed by CHEEBO, with
precise pressure adjustment control.
● Digital LED display, the equipment parameters are more intuitive
to adjust, easy to learn and operate.
● Microcomputer technology control, power grid voltage control,
automatic tracking compensation.
● Portable lithium battery spot welder with all-in-one design,
space-saving and easy to carry.
● The welder can pre-store several programs, which can be changed
and recalled at will.
● Compact structure, small size, high power, large industrial
circuit design, safe and reliable welding process.
Product introduction
This product is currently widely popular AC pulse spot welding
machine, using microcomputer single-chip microcomputer control,
stable and
reliable performance. Industrial grade welding equipment. It is
used for power lithium-ion battery module welding, 3C lithium-ion
battery pack
welding, nickel-metal hydride battery pack welding, hardware small
parts welding, electronic and electrical parts welding, wire
terminal welding,
stainless steel parts welding, metal jewelry, copper products,
aluminum products, etc. At the same time, it is also suitable for
product maintenance
and proofing.
Technical specification
| Welding thickness | 0.04-0.2MM | Welding power supply | Multiple-pulse |
| Welding mode | Single side double point horizontal welding | Table top and weld head height | 150MM (Maximum pitch adjustable) |
| Supply current | 3200A | Welding speed | 200P/M |
| Spot welding method | Bump welding/tip welding | Welding pressure | 5KG/F |
| Equipment power | 12KW | Equipment size | 640*200*360MM |
| Driving mode | Pneumatic | Machine Weight | 25KG |
| Power source specification | Single-phase 220V50/60HZ | Application scenarios | Battery welding |
Welding case
Function Introduction
1. Pneumatic precision welding head
The left and right electrodes of the double point welding head are
pressed down simultaneously, which is precise and adjustable.
Flexible and rapid pressurization, with good pressure follow-up.
High machining accuracy and low electrode inertia. The built-in
pressure in place sensing device is connected to the welding
controller to ensure that each welding pressure meets the
requirements.
2. Pressure regulation
The welding head pressure is adjustable from 1-10KG to ensure good
welding results of different thicknesses and materials.
3. Operation panel
LED digital display. "+", "-" to adjust the data. "#" switch to
adjust the data. Data adjustment is simple and convenient.
One-click switch button.
Debugging project
- Welding pressure: 1-5 kg/F
- Welding energy adjustment: "+" to increase energy, "-" to reduce
energy, "#" to switch parameters
- Air pressure regulation
- Adjustment of needle extension length
- Adjust the position under the table top
- Adjust the spacing between the left and right pins
